Bannerengineering SLE5-PIR-2M SLE5 Series Optical Label Sensor
Technical Specifications of Banner SLE5 Series Optical Label Sensor SLE5-PIR-2M:
| Max Sensing Range (mm) | 5 |
| Power Supply/Supply Voltage | 10-30 V dc |
Bannerengineering SLE5 Series Optical Label Sensor SLE5-PIR-2M Technical Specifications
| Specification | Value |
|---|---|
| IP Rating | IP65 |
| Connection | Cable |
| Sensing Mode (Detailed) | Emitter/Receiver Pair |
| Primary Housing Material | Zinc Alloy Die-Cast |
| Adjustments | Teach Button |
| Outputs | PNP |
| Special Feature: Remote Teach | Yes |
| Max Sensing Range (mm) | 5 |
| Power Supply/Supply Voltage | 10-30 V dc |
| Number of Pins | 5 |
| Indicator | LEDs |
| Operation | Light/Dark Operate |
| Output response time (ms) | 0.04 |
| Max Op. Temperature (Β°C) | 55 |
| Min Op. Temperature (Β°C) | -20 |
| Cable Length (m) | 2 |
| Housing Style | Label |
| Slot Depth/Array Length (mm) | 50 |
| Slot Overall Depth (mm) | 50 |
