Bannerengineering SLE30B6VY SLE10 & SLE30 Series Programmable Slot Sensors
Technical Specifications of Banner SLE10 & SLE30 Series Programmable Slot Sensors SLE30B6VY:
| Max Sensing Range (mm) | 30 |
| Power Supply/Supply Voltage | 10-30 V dc |
| NEMA / UL Type Rating | NEMA 4X |
Bannerengineering SLE10 & SLE30 Series Programmable Slot Sensors SLE30B6VY Technical Specifications
| Specification | Value |
|---|---|
| IP Rating | IP67 |
| Connection | Cable |
| Sensing Mode (Detailed) | Emitter/Receiver Pair |
| Primary Housing Material | Thermoplastic |
| NEMA / UL Type Rating | NEMA 4X |
| Adjustments | Teach Button |
| Outputs | Bipolar (NPN & PNP) |
| Special Feature: Remote Teach | Yes |
| Max Sensing Range (mm) | 30 |
| Power Supply/Supply Voltage | 10-30 V dc |
| Number of Pins | 5 |
| Indicator | LEDs |
| Operation | Light/Dark Operate |
| Output response time (ms) | 0.15 |
| Repeatability (Β΅s) | 75 |
| Lens Material | Acrylic |
| Max Op. Temperature (Β°C) | 60 |
| Min Op. Temperature (Β°C) | -20 |
| Max Op. Relative Humidity (%) | 90% @ 50Β°C |
| Delay at Power-up (ms) | 1000 |
| Cable Length (m) | 2 |
| Housing Style | Slot |
| Slot Depth/Array Length (mm) | 45 |
| Slot Overall Depth (mm) | 72 |
| Minimum Object Detection [mm] | 1.8 |
| Minimum Object Detection (mm) | 1.8 |
