Bannerengineering SLE3-PIR-Q7 Label Sensors
Technical Specifications of Banner Label Sensors SLE3-PIR-Q7:
| Connection | Integral QD |
| Max Sensing Range (mm) | 3 |
| Power Supply/Supply Voltage | 4.75-30 V dc |
Bannerengineering Label Sensors SLE3-PIR-Q7 Technical Specifications
| Specification | Value |
|---|---|
| Type | SLE3 Series Optical Label Sensor |
| IP Rating | IP65 |
| Connection | Integral QD |
| Quick Disconnect Type | M8 |
| Sensing Mode (Detailed) | Emitter/Receiver Pair |
| Primary Housing Material | Polycarbonate |
| Adjustments | Teach Button |
| Outputs | PNP |
| Special Feature: Remote Teach | Yes |
| Max Sensing Range (mm) | 3 |
| Power Supply/Supply Voltage | 4.75-30 V dc |
| Number of Pins | 4 |
| Indicator | LEDs |
| Operation | Light/Dark Operate |
| Output response time (ms) | 0.04 |
| Max Op. Temperature (Β°C) | 70 |
| Min Op. Temperature (Β°C) | -40 |
| Feature: Quick Disconnect | Yes |
| Housing Style | Label |
| Slot Depth/Array Length (mm) | 44 |
| Slot Overall Depth (mm) | 44 |
| Number of Beams | 1 |
