Bannerengineering SAB-497AB1LP6-Q5E Array Sensors
Technical Specifications of Banner Array Sensors SAB-497AB1LP6-Q5E:
| Max Sensing Range (mm) | 1000 |
| Power Supply/Supply Voltage | 10-30 V dc |
| NEMA / UL Type Rating | N/A |
Bannerengineering Array Sensors SAB-497AB1LP6-Q5E Technical Specifications
| Specification | Value |
|---|---|
| Type | SAB Sensor Array Bar Series |
| NEMA / UL Type Rating | N/A |
| IP Rating | IP50 |
| Cable Length (m) | 0.2 |
| Housing Style | Sensing Array Bar |
| Primary Housing Material | Black Anodized Aluminum |
| Max Sensing Range (mm) | 1000 |
| Slot Depth/Array Length (mm) | 497 |
| Connection | Pigtail QD |
| Quick Disconnect Type | M12 |
| Outputs | Bipolar (NPN & PNP) |
| Slot Overall Depth (mm) | 38 |
| Number of Pins | 4 |
| Power Supply/Supply Voltage | 10-30 V dc |
| Output response time (ms) | 1.5 |
| Adjustments | N/A |
| Lens Material | Acrylic |
| Delay at Power-up (ms) | N/A |
| Operation | Light Operate |
| Indicator | Indicator LEDs |
| Max Op. Temperature (°C) | 55 |
| Min Op. Temperature (°C) | -20 |
| Max Op. Relative Humidity (%) | 95% @ 50°C |
| Feature: Quick Disconnect | Yes |
| Number of Beams | 6 |
| Beam to Beam Spacing [mm] | 82.55 |
| Distance to First Beam [mm] | 42 |
