Banner S22RMTSGRCT Touch Button
The Banner S22RMTSGRCT Touch Button offers a Barrel Mount - Flat Window housing style, Terminal Connection, Normally Closed operation, and IP66, IP67, IP69K rating. Manufactured by Banner under the Banner Touch Button category, this model belongs to the K30 Series.
| Connection | Terminal |
| Color Technology | RGB Configurable |
| Supply Voltage | 10-30 V dc |
Banner S22RMTSGRCT Touch Button - Technical Specifications
| Specification | Value |
|---|---|
| Type | S22 Pro Series 22 mm Programmable Multicolor Touch Button |
| Housing Style | Barrel Mount - Flat Window |
| IP Rating | IP66, IP67, IP69K |
| Power | DC |
| Primary Housing Material | Polycarbonate |
| Connection | Terminal |
| Operation | Normally Closed |
| Feature: Audible | No |
| Display | No |
| Mounting Thread | M22 x 1.5 |
| Color Input Control | Individual (One wire/color, same number of colors as input wires) |
| Number of Colors | 2 |
| Product Size (mm) | 22 |
| Color Technology | RGB Configurable |
| Color Option 1 | Green |
| Color Option 2 | Red |
| Max Current Color (mA) | 80 |
| Number of Input Pins/Conductors | 5 |
| Supply Voltage | 10-30 V dc |
| Input Type | Bimodal (PNP/NPN) |
| Max Input Response Time (ms) | 20 |
| Physical Dimensions (LxWxH or DxH mm) | 27.3 x 39.1 |
| Environmental Rating | IP66; IP67; IP69K |
| High Temperature (up to 100° C) | 50 |
| Min Op. Temperature (°C) | -40 |
| Primary Housing Color | Black |
| Primary Window Material | Polycarbonate Diffused |
| Multi-Color Device | Single Color On |
| Max Op. Relative Humidity Non-Condensing (%) | 90% @ 50°C |
| Storage Temp (°C) | -40 to 70 |
| Activation Function | Capacitive Touch |
| Acknowledge (Sense) Light | Red |
| Pick-to-Light Function | C |
| Output Type | Bipolar (NPN & PNP) |
| Max Output Response Time (ms) | 300 |
| Button Operation | Momentary |
| Job Light | Green |
| Lumens Color 1 | 0.18 |
| Color 1 - Wavelength/Color Temp/Coordinates | 527 nm |
| Lumens Color 2 | 0.08 |
| Color 2 - Wavelength/Color Temp/Coordinates | 625 nm |
