Banner S22AMTSYGCQP Touch Button
The Banner S22AMTSYGCQP Touch Button offers a Barrel Mount - Flat Window housing style, Pigtail QD Connection, Normally Open operation, and IP66, IP67, IP69K rating. Manufactured by Banner under the Banner Touch Button category, this model belongs to the K30 Series.
| Connection | Pigtail QD |
| Color Technology | RGB Configurable |
| Supply Voltage | 10-30 V dc |
Banner S22AMTSYGCQP Touch Button - Technical Specifications
| Specification | Value |
|---|---|
| Type | S22 Pro Series 22 mm Programmable Multicolor Touch Button |
| Housing Style | Barrel Mount - Flat Window |
| IP Rating | IP66, IP67, IP69K |
| Cable Length (m) | 0.15 |
| Power | DC |
| Primary Housing Material | Polycarbonate |
| Connection | Pigtail QD |
| Operation | Normally Open |
| Feature: Audible | No |
| Display | No |
| Mounting Thread | M22 x 1.5 |
| Color Input Control | Individual (One wire/color, same number of colors as input wires) |
| Number of Colors | 2 |
| Product Size (mm) | 22 |
| Color Technology | RGB Configurable |
| Color Option 1 | Yellow |
| Quick Disconnect Type | M12 |
| Color Option 2 | Green |
| Max Current Color (mA) | 80 |
| Number of Input Pins/Conductors | 5 |
| Supply Voltage | 10-30 V dc |
| Input Type | Bimodal (PNP/NPN) |
| Max Input Response Time (ms) | 20 |
| Physical Dimensions (LxWxH or DxH mm) | 27.3 x 47.8 |
| Environmental Rating | IP66; IP67; IP69K |
| High Temperature (up to 100Β° C) | 50 |
| Min Op. Temperature (Β°C) | -40 |
| Primary Housing Color | Black |
| Primary Window Material | Polycarbonate Diffused |
| Multi-Color Device | Single Color On |
| Max Op. Relative Humidity Non-Condensing (%) | 90% @ 50Β°C |
| Storage Temp (Β°C) | -40 to 70 |
| Activation Function | Capacitive Touch |
| Acknowledge (Sense) Light | Green |
| Pick-to-Light Function | C |
| Output Type | Bipolar (NPN & PNP) |
| Max Output Response Time (ms) | 300 |
| Button Operation | Momentary |
| Job Light | Yellow |
| Lumens Color 1 | 0.25 |
| Color 1 - Wavelength/Color Temp/Coordinates | 572 nm |
| Lumens Color 2 | 0.18 |
| Color 2 - Wavelength/Color Temp/Coordinates | 527 nm |
