Banner S15YB-M124-M124-0.2M Cordset
The Banner S15YB-M124-M124-0.2M Cordset offers a , connection, 30 V ac/dc rating, and No Shield. Manufactured by Banner under the Banner Cordset category.
| Brand | Banner |
| Product Type | Cordsets |
| Model Number | S15YB-M124-M124-0.2M |
Banner S15YB-M124-M124-0.2M Cordset – Technical Specifications
| Specification | Value |
|---|---|
| IP Rating | IP67 |
| Cordset Length (m) | 0.2 |
| Voltage Rating (V) | 30 V ac/dc |
| Minimum Temp. (Celsius) | -40 |
| Shield/No Shield | No Shield |
| Current Rating (A) | 4 |
| Maximum Temp. (Celsius) | 70 |
| Cordset Length Range (m) | Less than 2.00 |
| Branches: Orientations | Straight, Straight |
| Branches: Genders | Female, Female |
| Branches: Number of Contacts | 4, 4 |
| Branches: Connector Types | M12, M12 |
| Branches: Cable Jacket Material | PVC, PVC |
| Splitter: Overmold Material and Color | PUR Black |
| Wiring | Parallel |
| Number of Branches | 2 |
| Trunk: Connector Type | M12 |
| Trunk: Number of Contacts | 4 |
| Trunk: Orientation | Straight |
| Trunk: Gender | Male |
