Banner RDLP-8100D Cordset
The Banner RDLP-8100D Cordset offers a Single Ended, LP-Custom connection, 60 V ac/75 V dc rating, and No Shield. Manufactured by Banner under the Banner Cordset category.
| Brand | Banner |
| Product Type | Cordsets |
| Model Number | RDLP-8100D |
Banner RDLP-8100D Cordset β Technical Specifications
| Specification | Value |
|---|---|
| IP Rating | IP67 |
| Cable Jacket Color | Yellow |
| Cable Jacket Material | PVC |
| Connector 1 Gender | Male |
| Connector 1 Orientation | Straight |
| Cordset Length (m) | 30.5 |
| Outside Cable Diameter (mm) | 6 |
| Connector 1 Number of Contacts | 8 |
| Number of Ends | Single Ended |
| Connector 2 Type | Flying Leads |
| Connector 1 Type | LP-Custom |
| Voltage Rating (V) | 60 V ac/75 V dc |
| Trunk Length (m) | No Trunk |
| Shield/No Shield | No Shield |
| Overmold Material and Color | TPU Black |
| Current Rating (A) | 2 |
| Maximum Temp. (Celsius) | 55 |
| Cordset Length Range (m) | Greater than 20.00 |
