Banner QS18VP6F: Fiber Optic Amplifiers
The Banner QS18VP6F Fiber Optic Amplifiers offers a Glass Only fiber type, PNP output, and Cable connection. Manufactured by Banner under the Banner Fiber Optic Amplifiers category, this model belongs to the DF Series.
| Output Type (Specific) | Single Discrete |
| Repeatability (Β΅s) | 150 |
| Power Supply/Supply Voltage | 10-30 V dc |
Banner Fiber Optic Amplifiers QS18VP6F Technical Specifications
| Specification | Value |
|---|---|
| Type | QS18 Series All Purpose Fiber Optic Amplifier |
| IP Rating | IP67 |
| Accepts Fiber Termination Type | Glass Fiber Termination |
| NEMA / UL Type Rating | NEMA 4X |
| Power | DC |
| Housing Style | Rectangular w/M18 Mount |
| Primary Housing Material | Thermoplastic |
| Input Output | Discrete |
| Color LED - Amplifiers | Infrared |
| Fiber Type | Glass Only |
| Connection | Cable |
| Output | PNP |
| Output Type (Specific) | Single Discrete |
| Repeatability (Β΅s) | 150 |
| Number of Pins | 4 |
| Max Op. Temperature (Β°C) | 70 |
| Min Op. Temperature (Β°C) | -20 |
| Max Op. Relative Humidity (%) | 95% @ 50Β°C |
| Special Feature: Remote Teach | No |
| Intrinsically Safe | No |
| Adjustments | Potentiometer |
| Power Supply/Supply Voltage | 10-30 V dc |
| Delay at Power-up (ms) | 100 |
| Indicator Display Type | Indicator LEDs |
| Minimum response time (ms) | 0.6 |
| Special Feature: Bussable Power | No |
| Feature: Audible | No |
| Cable Length (m) | 2 |
| Housing Material | Thermoplastic |
