Banner QS18EK6FPQ5: Fiber Optic Amplifiers
The Banner QS18EK6FPQ5 Fiber Optic Amplifiers offers a Plastic and Glass fiber type, 2 NPN/2 PNP Configurable output, and Pigtail QD connection. Manufactured by Banner under the Banner Fiber Optic Amplifiers category, this model belongs to the DF Series.
| Output Type (Specific) | IO-Link and Single Discrete |
| Repeatability (Β΅s) | 75 |
| Power Supply/Supply Voltage | 10-30 V dc |
Banner Fiber Optic Amplifiers QS18EK6FPQ5 Technical Specifications
| Specification | Value |
|---|---|
| Type | QS18 Series All Purpose Fiber Optic Amplifier |
| IP Rating | IP67 |
| Accepts Fiber Termination Type | Unterminated Plastic Fibers or T5 Termination |
| NEMA / UL Type Rating | NEMA 4X |
| Power | DC |
| Housing Style | Rectangular |
| Primary Housing Material | Thermoplastic |
| Input Output | Discrete & Serial |
| Color LED - Amplifiers | Red |
| Fiber Type | Plastic and Glass |
| Connection | Pigtail QD |
| Output | 2 NPN/2 PNP Configurable |
| Quick Disconnect Type | M12 |
| Output Type (Specific) | IO-Link and Single Discrete |
| Repeatability (Β΅s) | 75 |
| Number of Pins | 4 |
| Max Op. Temperature (Β°C) | 70 |
| Min Op. Temperature (Β°C) | -20 |
| Max Op. Relative Humidity (%) | 95% @ 50Β°C |
| Special Feature: Remote Teach | Yes |
| Intrinsically Safe | No |
| Adjustments | Teach Button |
| Power Supply/Supply Voltage | 10-30 V dc |
| Delay at Power-up (ms) | 100 |
| Indicator Display Type | Indicator LEDs |
| Minimum response time (ms) | 0.6 |
| Special Feature: Bussable Power | No |
| Feature: Timing (Hold/Delay) | Yes |
| Feature: Audible | No |
| Feature: Quick Disconnect | Yes |
| Feature: Health/Marginal Signal Output | Yes |
| IO Link | Yes |
| Cable Length (m) | 0.15 |
