Bannerengineering Q26NLUMQ5 Registration Mark, Color and Luminescence Sensors
Technical Specifications of Banner Registration Mark, Color and Luminescence Sensors Q26NLUMQ5:
| Connection | Pigtail QD |
| Max Sensing Range (mm) | 30 |
| Power Supply/Supply Voltage | 12-30 V dc |
| NEMA / UL Type Rating | NEMA 4X |
Bannerengineering Registration Mark, Color and Luminescence Sensors Q26NLUMQ5 Technical Specifications
| Specification | Value |
|---|---|
| Type | Q26 Series Compact Luminescence Sensor |
| IP Rating | IP67 |
| Connection | Pigtail QD |
| Quick Disconnect Type | M12 |
| Primary Housing Material | Thermoplastic |
| NEMA / UL Type Rating | NEMA 4X |
| Adjustments | Teach Button |
| Sensing Beam | Black Ultraviolet LED |
| Outputs | NPN |
| Special Feature: Remote Teach | Yes |
| Sensing Beam Wavelength | 375 |
| Max Sensing Range (mm) | 30 |
| Power Supply/Supply Voltage | 12-30 V dc |
| Number of Pins | 4 |
| LED Orientation | Parallel to sensor length |
| Indicator | LEDs |
| Operation | Light/Dark Operate |
| Output response time (ms) | 0.25 |
| Lens Material | Polycarbonate |
| Max Op. Temperature (°C) | 55 |
| Min Op. Temperature (°C) | -10 |
| Special Feature: Analog Output | No |
| Beam Spot Size | 1 mm at 12 mm |
| Feature: Quick Disconnect | Yes |
| Application: Luminescence | Yes |
| Application: Registration Mark | No |
| Application: Color | No |
| Cable Length (m) | 0.15 |
