Banner PVS28D100QP Lighting and Indication
The Banner PVS28D100QP Lighting and Indication offers a Flat Mount - Array style, Bimodal (PNP/NPN) input type, 12-30 V dc supply voltage, and Pigtail QD connection. Manufactured by Banner under the Banner Lighting and Indication category, this model belongs to the Andon lights.
| Brand | Banner |
| Product Type | Lighting and Indication |
| Model Number | PVS28D100QP |
Banner PVS28D100QP Lighting and Indication – Technical Specifications
| Specification | Value |
|---|---|
| Housing Style | Flat Mount - Array |
| Sensing Mode (General) | Proximity |
| Sensing Mode (Detailed) | Diffuse/Background Suppression |
| IP Rating | IP54 |
| Cable Length (m) | 0.15 |
| Power | DC |
| Primary Housing Material | Polycarbonate |
| Connection | Pigtail QD |
| Operation | Normally Open/Normally Closed |
| Feature: Audible | No |
| Display | No |
| Mounting Thread | No Thread |
| Color Input Control | Individual (One wire/color, same number of colors as input wires) |
| Number of Colors | 2 |
| Product Size (mm) | 100 |
| Color Technology | Standard LED |
| Color Option 1 | Green |
| Animation Option 1 | Solid On |
| Color Option 2 | Red |
| Color Option 3 | Yellow |
| Max Current Color (mA) | 110 |
| Number of Input Pins/Conductors | 5 |
| Supply Voltage | 12-30 V dc |
| Input Type | Bimodal (PNP/NPN) |
| Max Input Response Time (ms) | 40 |
| Physical Dimensions (LxWxH or DxH mm) | 142 x 30.0 x 15.0 |
| High Temperature (up to 100° C) | 50 |
| Min Op. Temperature (°C) | -20 |
| Primary Housing Color | Black |
| Primary Window Material | Polycarbonate |
| Feature: Quick Disconnect | Yes |
| Number of Beams | 2 |
| Array Length (mm) | 100 |
| Storage Temp (°C) | -40 to 70 |
| Actuation | Yes |
| Activation Function | Optical |
| Output Type | Bipolar (NPN or PNP - user selectable) |
| Max Output Response Time (ms) | 120 |
| Button Operation | Momentary |
| Maximum Sensing Distance (mm) | 500 |
| Lumens Color 1 | 12 |
| Color 1 - Wavelength/Color Temp/Coordinates | 525 nm |
| Lumens Color 2 | 2.5 |
| Color 2 - Wavelength/Color Temp/Coordinates | 620 nm |
| Lumens Color 3 | 2.5 |
| Color 3 - Wavelength/Color Temp/Coordinates | 576 nm |
| Beam Spacing (mm) | 50 |
| Sensing Resolution (mm) | 20 |
