Banner PBA26UM13X7MTM Fiber Optic Sensor
The Banner PBA26UM13X7MTM Fiber Optic Sensor offers a Diffuse sensing mode, 1 bend radius, Plastic fiber optic type, and Plastic Fiber Sensors termination type. Manufactured by Banner under the Banner Fiber Optic Sensor category, this model belongs to the PIF46U Series.
| Brand | Banner |
| Product Type | Fiber Optic Sensor |
| Model Number | PBA26UM13X7MTM |
Banner PBA26UM13X7MTM Fiber Optic Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Housing Style | Rectangular |
| Quantity Included | 1 |
| Fiber Optic Type | Plastic |
| Sensing Mode (General) | Diffuse |
| Sensing Mode (Detailed) | Reflective |
| Beam Exit | Right Angle |
| Sensing End Material (Specific) | Stainless Steel |
| Fiber Sheathing Material (Jacket) | Polyethylene |
| Fiber Sensing End Tip | Sideview |
| Fiber Length (m) | 1 |
| Fiber Sensing End Size | 13.0 x 7.0 mm |
| Sensing End Segment 1 | Rectangle |
| Retractile | No |
| Flex Relief | Yes |
| Core Diameter (mm) | 0.5 |
| Minimum Bend Radius (mm) | 1 |
| Termination | Free Cut |
| Max Temp ( °C) | 70 |
| Minimum Repeat Bending Endurance | 2000 |
| Integrated Lens | No |
| Application: Liquid Level | No |
| Termination Type | Plastic Fiber Sensors |
| Fiber Sensing End Size - Mounting Area | 13.0 x 7.0 mm |
| Tariff Fiber Meters (fbm) | 2 |
| Sensing End Segment 2 | Sideview |
