Banner OTBA5L Touch Button
The Banner OTBA5L Touch Button offers a Base Mount - Saddle housing style, Cable Connection, Normally Open/Normally Closed operation, and IP66 rating. Manufactured by Banner under the Banner Touch Button category, this model belongs to the K30 Series.
| Brand | Banner |
| Product Type | Tower Button |
| Model Number | OTBA5L |
Banner OTBA5L Touch Button - Technical Specifications
| Specification | Value |
|---|---|
| Type | OTB Series Optical Touch Buttons |
| Housing Style | Base Mount - Saddle |
| Sensing Mode (General) | Single Point Optical |
| IP Rating | IP66 |
| Cable Length (m) | 2 |
| Power | AC |
| Primary Housing Material | Polycarbonate |
| Connection | Cable |
| Operation | Normally Open/Normally Closed |
| Mounting Thread | M30 x 1.5 |
| Product Size (mm) | Other |
| Number of Input Pins/Conductors | 5 |
| Supply Voltage | 105-130 V ac |
| Input Type | AC |
| Max Input Response Time (ms) | 100 |
| Physical Dimensions (LxWxH or DxH mm) | 59.9 x 43.2 x 48.0 |
| Environmental Rating | IP66 |
| High Temperature (up to 100° C) | 50 |
| Min Op. Temperature (°C) | -20 |
| Primary Housing Color | Red |
| Output Type | SPDT e/m Relay |
| Max Output Response Time (ms) | 100 |
