Banner MQDC-WDSS-0815 Cordset
The Banner MQDC-WDSS-0815 Cordset offers a Single Ended, M12 connection, 75 V ac/dc rating, and No Shield. Manufactured by Banner under the Banner Cordset category.
| Brand | Banner |
| Product Type | Cordsets |
| Model Number | MQDC-WDSS-0815 |
Banner MQDC-WDSS-0815 Cordset β Technical Specifications
| Specification | Value |
|---|---|
| IP Rating | IP69 |
| Feature: Washdown Rated | Yes |
| Cable Jacket Color | Black |
| Connector 1 Key Code | A |
| Cable Jacket Material | PVC |
| Coupling Nut Material | 316 Stainless Steel |
| Connector 1 Gender | Female |
| Connector 1 Orientation | Straight |
| Cordset Length (m) | 5 |
| Outside Cable Diameter (mm) | 5.92 |
| Connector 1 Number of Contacts | 8 |
| Number of Ends | Single Ended |
| Connector 2 Type | Flying Leads |
| Connector 1 Type | M12 |
| Voltage Rating (V) | 75 V ac/dc |
| Minimum Temp. (Celsius) | -40 |
| Trunk Length (m) | No Trunk |
| Shield/No Shield | No Shield |
| Overmold Material and Color | PVC Black |
| Current Rating (A) | 2 |
| Maximum Temp. (Celsius) | 70 |
| Cordset Length Range (m) | 5.00-9.99 |
