Banner MMD-TA-11B Safety Relay
The Banner MMD-TA-11B Safety Relay offers 3, rating, Screw terminal type. Manufactured by Banner under the Banner Safety Relay category, this model belongs to the ATK Series.
| Supply Voltage | 24 V dc +/- 15% |
| Safe Output Rating | Relay - 6 A |
| Power Consumption | 0.3 A |
Banner MMD-TA-11B Safety Relay β Technical Specifications
| Specification | Value |
|---|---|
| Type | MMD Series Muting Safety Relays |
| IP Rating | IP20 |
| Power | DC |
| Supply Voltage | 24 V dc +/- 15% |
| Device Type | Safety Relay |
| PL Rating | e |
| SIL Rating | 3 |
| Vibration | 10-55 Hz at 0.35 mm |
| LCD Display | No |
| In-Series Diagnostics | No |
| Max Operating Temperature ( Β°C) | 50 |
| Relative Humidity | 95% @ 50Β° C |
| SISTEMA | PFHd = 2 x 10-9 |
| Safety Module Type | Muting Module |
| Expandable | No |
| Dimension (H x W x D in mm) | 84 x 67.5 x 118 |
| Input Operation | Simultaneous within 3.0 s |
| Number of Safe Inputs | 2 |
| Input Configuration | 2 NC, 1 NC, or 2 PNP |
| Safety Input - Dual Channel (Solid-State) | 10-50 mA @ 15-30 V dc |
| Independently Controlled Safe Outputs | 1 |
| Output Configuration | 2 NO |
| Non Safe Output Rating | Relay - 6 A |
| Safe Output Rating | Relay - 6 A |
| Splittable Safe Output | No |
| Mechanical Life (Operations in Millions) | 50 |
| Power Consumption | 0.3 A |
| Response Time (ms) | 20 (max.) |
| Terminal Type | Screw |
| Removable Terminals | Yes |
| Electrical Life (Cycles @ VA) | 120,000 @ 1380 VA |
| Safety Category Rating | 4 |
| E-Stops/Rope Pulls | Yes |
| Safety Mat | No |
| Motor Speed | No |
| Muting | Yes |
| Gate Switch (NC/NC) Input | Yes |
| Gate Switch (NC/NO) Input | No |
| Gate Switch (OSSD) Input | Yes |
| Light Curtains/Scanner with EDM Input | Yes |
| Light Curtains/Scanner without EDM Input | Yes |
| Non Safe Output Configuration | 1 NC |
| Safety Input - Dual Channel (Dry Contact) | 10-50 mA @ 15-30 V dc |
| Safety Input - Reset | 10-50 mA @ 15-30 V dc |
| Input Resistance | 400 Ξ© max. per channel |
