Bannerengineering MAHE32A: MINI-ARRAY High-Resolution Measuring Light Curtain
Technical Specifications of Banner MINI-ARRAY High-Resolution Measuring Light Curtain MAHE32A:
| Sensing Mode (Detailed) | Emitter |
| Power Supply | 12 V dc |
Bannerengineering MINI-ARRAY High-Resolution Measuring Light Curtain MAHE32A Technical Specifications
| Specification | Value |
|---|---|
| Sensing Mode (Detailed) | Emitter |
| Primary Housing Material | Aluminum |
| Housing Length (mm) | 887 |
| Device Type | Three-Piece |
| Beam Spacing | 2.5 mm |
| Power Supply | 12 V dc |
| Emitter/Receiver Range (m) | 0.38 - 1.8 |
| Max Relative Humidity | 95% |
| Minimum Object Sensitivity (mm) | 2.5 |
| Number of Beams | 320 |
| Max Temp (°C) | 50 |
| Array Length (mm) | 813 |
