Bannerengineering M18TIP8: Temperature & Vibration Sensors
Technical Specifications of Banner Temperature & Vibration Sensors M18TIP8:
| Sensing Mode (Detailed) | Diffuse |
| Power Supply | 12-30 V dc |
| Minimum Response Time (ms) | 25 |
| NEMA / UL Type Rating | NEMA 4X |
Bannerengineering Temperature & Vibration Sensors M18TIP8 Technical Specifications
| Specification | Value |
|---|---|
| Type | M18T Series Non-Contact Temperature Sensors |
| Cable Length (m) | 2 |
| PC Configurable | Yes |
| Power | DC |
| NEMA / UL Type Rating | NEMA 4X |
| IP Rating | IP67 |
| Sensing Mode (General) | Proximity |
| Sensing Mode (Detailed) | Diffuse |
| Housing Style | Barrel |
| Device Type | Sensor |
| Primary Housing Material | Stainless Steel |
| Input Output | Analog |
| Analog Output Configuration | 4-20 mA |
| Connection | Flying Leads |
| Power Supply | 12-30 V dc |
| Adjustments | Push Button; Remote Teach |
| Number of Pins | 5 |
| Max Operating Temperature (Β°C) | 70 |
| Min Operating Temperature (Β°C) | -20 |
| Minimum Response Time (ms) | 25 |
| Barrel Thread | M18 |
| Feature: Remote Teach | Yes |
| Feature: Chemical Resistant | Yes |
| Feature: Quick Disconnect | Yes |
| Feature: Health/Marginal Signal Output | Yes |
