Bannerengineering M18RGX7PQPMA LED Indicators
Technical Specifications of Banner LED Indicators M18RGX7PQPMA:
| Housing Style | Barrel Mount - Flat Window |
| Connection | Pigtail PUR QD |
| Supply Voltage | 10-30 V dc |
| Input Type | PNP |
Bannerengineering LED Indicators M18RGX7PQPMA Technical Specifications
| Specification | Value |
|---|---|
| Type | 18 mm Metal Barrel General Purpose Indicators: M18 Series |
| Housing Style | Barrel Mount - Flat Window |
| IP Rating | IP67 |
| Power | DC |
| Primary Housing Material | Nickel-Plated Brass |
| Connection | Pigtail PUR QD |
| Feature: Audible | No |
| Display | No |
| Indication | Yes |
| Mounting Thread | M18 x 1.0 |
| Color Input Control | Individual (One wire/color, same number of colors as input wires) |
| Number of Colors | 2 |
| Product Size (mm) | 18 |
| Color Technology | Standard LED |
| Color Option 1 | Red |
| Animation Option 1 | Solid On |
| Quick Disconnect Type | M12 |
| Color Option 2 | Green |
| Max Current Color (mA) | 25 |
| Number of Input Pins/Conductors | 4 |
| Supply Voltage | 10-30 V dc |
| Input Type | PNP |
| Max Input Response Time (ms) | 1 |
| Physical Dimensions (LxWxH or DxH mm) | 16.5 x 51.5 |
| Environmental Rating | IP67 |
| High Temperature (up to 100Β° C) | 50 |
| Min Op. Temperature (Β°C) | -40 |
| Primary Window Material | Thermoplastic Diffused |
| Multi-Color Device | Single Color On |
| Feature: Quick Disconnect | Yes |
| Application: Photoelectric Sensors | Yes |
