Banner LCA130T5DXN2Q Lighting and Indication
The Banner LCA130T5DXN2Q Lighting and Indication offers a Enclosure style, Bimodal (PNP/NPN) input type, 18-30 V dc supply voltage, and Integral QD connection. Manufactured by Banner under the Banner Lighting and Indication category, this model belongs to the Andon lights.
| Brand | Banner |
| Product Type | Lighting and Indication |
| Model Number | LCA130T5DXN2Q |
Banner LCA130T5DXN2Q Lighting and Indication – Technical Specifications
| Specification | Value |
|---|---|
| Housing Style | Enclosure |
| IP Rating | IP65 |
| Power | DC |
| Primary Housing Material | Polycarbonate |
| Connection | Integral QD |
| Feature: Audible | No |
| Display | No |
| Mounting Thread | No Thread |
| Number of Colors | 14 |
| Color Technology | RGB Configurable |
| Quick Disconnect Type | M12 |
| Max Current Color (mA) | 50 |
| Number of Input Pins/Conductors | 4 |
| Supply Voltage | 18-30 V dc |
| Input Type | Bimodal (PNP/NPN) |
| Max Input Response Time (ms) | 10 |
| High Temperature (up to 100° C) | 50 |
| Min Op. Temperature (°C) | -40 |
| Primary Housing Color | Black |
| Primary Window Material | Polycarbonate Diffused |
| Multi-Color Device | Simultaneous Colors On |
| Feature: Quick Disconnect | Yes |
| Max Op. Relative Humidity Non-Condensing (%) | 95% @ 50°C |
| Actuation | Yes |
| Activation Function | Capacitive Touch |
| Button Operation | Latching |
| Wireless | Yes |
| Wireless Radio Frequency | 2.4 GHz |
| Wireless Network | Node |
