Bannerengineering K80LGRA1YN LED Indicators
Technical Specifications of Banner LED Indicators K80LGRA1YN:
| Housing Style | Flat Mount - Dome Window |
| Connection | Terminal |
| Supply Voltage | 18-30 V dc |
| Input Type | NPN |
Bannerengineering LED Indicators K80LGRA1YN Technical Specifications
| Specification | Value |
|---|---|
| Type | K80L Series Flat Mount Domed Indicators |
| Housing Style | Flat Mount - Dome Window |
| IP Rating | IP50 |
| Power | DC |
| Primary Housing Material | Polycarbonate |
| Connection | Terminal |
| Feature: Audible | Yes |
| Display | No |
| Indication | Yes |
| Mounting Thread | No Thread |
| Color Input Control | Individual (One wire/color, same number of colors as input wires) |
| Number of Colors | 2 |
| Product Size (mm) | 80 |
| Color Technology | Standard LED |
| Color Option 1 | Green |
| Animation Option 1 | Solid On |
| Color Option 2 | Red |
| Max Current Color (mA) | 40 |
| Number of Input Pins/Conductors | 5 |
| Supply Voltage | 18-30 V dc |
| Input Type | NPN |
| Max Input Response Time (ms) | 10 |
| Physical Dimensions (LxWxH or DxH mm) | 122.2 x 80.9 x 65.7 |
| Environmental Rating | IP50 |
| High Temperature (up to 100° C) | 50 |
| Min Op. Temperature (°C) | -20 |
| Primary Housing Color | Yellow |
| Primary Window Material | Acrylic Diffused |
| Multi-Color Device | Single Color On |
| Audible Alarm Type | Continuous |
| Max Audible Intensity (db at 1m) | 75 |
| Audible Operating Frequency (kHz) | 3 |
| Max Current - Audible Alarm (mA) | 40 |
