Banner K70LGRPQ Industrial Wireless

Name: Bannerengineering K70LGRPQ
Brand: IndMALL
SKU: 53cc03e42c13
Rating: 4.9 (4 reviews)

The Banner K70LGRPQ Industrial Wireless offers a PNP input type, 12-30 V dc power supply, 2 No.of colors, and IP65 rating. Manufactured by Banner under the Banner Industrial Wireless category, this model belongs to the K70 Series.

Datasheet

Color Input Control	Individual (One wire/color, same number of colors as input wires)
Number of Colors	2
Supply Voltage	12-30 V dc

Banner K70LGRPQ Industrial Wireless – Technical Specifications

Specification	Value
Type	Wireless K70 Series Indicators
Housing Style	Base Mount - Dome Window
IP Rating	IP65
Power	DC
Primary Housing Material	Polycarbonate
Connection	Integral QD
Feature: Audible	No
Display	No
Indication	Yes
Mounting Thread	M30 x 1.5
Color Input Control	Individual (One wire/color, same number of colors as input wires)
Number of Colors	2
Product Size (mm)	70
Color Technology	Standard LED
Color Option 1	Green
Animation Option 1	Solid On
Quick Disconnect Type	M12
Color Option 2	Red
Max Current Color (mA)	200
Number of Input Pins/Conductors	5
Supply Voltage	12-30 V dc
Input Type	PNP
Max Input Response Time (ms)	75
Environmental Rating	IP65
High Temperature (up to 100° C)	50
Min Op. Temperature (°C)	-40
Primary Housing Color	Black
Primary Window Material	Polycarbonate Diffused
Multi-Color Device	Single Color On
Feature: Quick Disconnect	Yes
Max Op. Relative Humidity Non-Condensing (%)	95% @ 50°C
Lumens Color 1	65
Color 1 - Wavelength/Color Temp/Coordinates	525 nm
Lumens Color 2	34
Color 2 - Wavelength/Color Temp/Coordinates	625 nm
