Bannerengineering K50LDGRYP LED Indicators
Technical Specifications of Banner LED Indicators K50LDGRYP:
| Housing Style | Base Mount - No Window |
| Connection | Cable |
| Supply Voltage | 15-30 V dc |
| Input Type | PNP |
Bannerengineering LED Indicators K50LDGRYP Technical Specifications
| Specification | Value |
|---|---|
| Type | K50L Series Daylight Visible Indicators |
| Housing Style | Base Mount - No Window |
| IP Rating | IP67 |
| Cable Length (m) | 2 |
| Power | DC |
| Primary Housing Material | Polycarbonate |
| Connection | Cable |
| Feature: Audible | No |
| Display | No |
| Indication | Yes |
| Mounting Thread | M30 x 1.5 |
| Color Input Control | Individual (One wire/color, same number of colors as input wires) |
| Number of Colors | 3 |
| Product Size (mm) | 50 |
| Color Technology | Standard LED |
| Color Option 1 | Green |
| Animation Option 1 | Solid On |
| Color Option 2 | Red |
| Color Option 3 | Yellow |
| Max Current Color (mA) | 40 |
| Number of Input Pins/Conductors | 4 |
| Supply Voltage | 15-30 V dc |
| Input Type | PNP |
| Max Input Response Time (ms) | 1 |
| Physical Dimensions (LxWxH or DxH mm) | 50.0 x 38.5 |
| Environmental Rating | IP67 |
| High Temperature (up to 100Β° C) | 50 |
| Min Op. Temperature (Β°C) | -40 |
| Primary Housing Color | Black |
| Multi-Color Device | Single Color On |
| Max Op. Relative Humidity Non-Condensing (%) | 90% @ 50Β°C |
| Indication Intensity | High Brightness & Daylight Visible |
