Banner K50APFF100GRYC3QPMA Lighting and Indication

Name: Bannerengineering K50APFF100GRYC3QPMA
Brand: Banner
SKU: K50APFF100GRYC3QPMA
Rating: 4.5 (4 reviews)

The Banner K50APFF100GRYC3QPMA Lighting and Indication offers a Base Mount - Dome Window style, PNP input type, 12-30 V dc supply voltage, and Pigtail PUR QD connection. Manufactured by Banner under the Banner Lighting and Indication category, this model belongs to the Andon lights.

Datasheet

Brand	Banner
Product Type	Lighting and Indication
Model Number	K50APFF100GRYC3QPMA

Banner K50APFF100GRYC3QPMA Lighting and Indication – Technical Specifications

Specification	Value
Housing Style	Base Mount - Dome Window
IP Rating	IP67, IP69K
Cable Length (m)	0.15
Quick Disconnect Type	M12
Power	DC
Primary Housing Material	Polycarbonate
Connection	Pigtail PUR QD
Actuation	Yes
Mounting Thread	M30 x 1.5
Color Input Control	Individual (One wire/color, same number of colors as input wires)
Number of Colors	3
Product Size (mm)	50
Color Technology	Standard LED
Color Option 1	Green
Animation Option 1	Solid On
Supply Voltage	12-30 V dc
Input Type	PNP
Max Current Color (mA)	90
Physical Dimensions (LxWxH or DxH mm)	50.0 x 56.8
Environmental Rating	IP67; IP69K
High Temperature (up to 100° C)	50
Min Op. Temperature (°C)	-40
Primary Housing Color	Black
