Bannerengineering EM-FD-7G3 - Safety Controllers and Safety Relays
Technical Specifications of Banner Safety Controllers and Safety Relays EM-FD-7G3:
| Supply Voltage | 24 V ac/dc +/- 10% |
| Safe Output Rating | Relay - 6 A |
| Power Consumption | 0.1 A |
Bannerengineering Safety Controllers and Safety Relays EM-FD-7G3 Technical Specifications
| Specification | Value |
|---|
| Type | EM Series Safety Extension Relays |
| IP Rating | IP20 |
| Power | AC/DC Universal |
| Supply Voltage | 24 V ac/dc +/- 10% |
| Device Type | Safety Relay |
| Vibration | 10-55 Hz at 0.35 mm |
| LCD Display | No |
| In-Series Diagnostics | No |
| Max Operating Temperature ( °C) | 50 |
| Relative Humidity | 90% @ 50° C |
| Safety Module Type | Relay Extension Module |
| Expandable | No |
| Dimension (H x W x D in mm) | 82 x 22.5 x 118 |
| Number of Safe Inputs | 1 |
| Input Configuration | 1 NC |
| Independently Controlled Safe Outputs | 1 |
| Output Configuration | 4 NO |
| Safe Output Rating | Relay - 6 A |
| Splittable Safe Output | No |
| Mechanical Life (Operations in Millions) | 10 |
| Power Consumption | 0.1 A |
| Response Time (ms) | 35 (typical) |
| Terminal Type | Screw |
| Removable Terminals | No |
| Electrical Life (Cycles @ VA) | 100,000 @ 1500 VA |
| E-Stops/Rope Pulls | No |
| Safety Mat | No |
| Motor Speed | No |
| Muting | No |
| Gate Switch (NC/NC) Input | No |
| Gate Switch (NC/NO) Input | No |
| Gate Switch (OSSD) Input | No |
| Light Curtains/Scanner with EDM Input | No |
| Light Curtains/Scanner without EDM Input | No |
| Safety Input - Single Channel | 40-100 mA @ 13-27 V ac/dc |
| Recovery Time (ms) | 30 |
