Banner ED1G-L20MB-1N Safety Switch
The Banner ED1G-L20MB-1N Safety Switch offers Enabling Switch, type, Wiring Chamber connection type. Manufactured by Banner under the Banner Safety Switch category, this model belongs to the SI Series.
| Device Type | Enabling Switch |
| Connection Type | Wiring Chamber |
Banner ED1G-L20MB-1N Safety Switch – Technical Specifications
| Specification | Value |
|---|---|
| Housing Style | HandleGrip Switch w/ Momentary Push Button |
| Device Type | Enabling Switch |
| IP Rating | IP65 |
| Primary Housing Material | Thermoplastic |
| Connection | Integral QD |
| Button Shroud | No |
| Contact Quantity | 2 NO, 2 NO Push-Button |
| Contact Rating | 2 A @ 24 V dc |
| Dimensions (HxWxD mm ) | 269 x 46 x 58 |
| Min Operating Temperature ( °C) | -10 |
| Max Operating Temperature ( °C) | 60 |
| Min Op. Temperature (°C) | -10 |
| Max Op. Temperature (°C) | 60 |
| Feature: Quick Disconnect | Yes |
| Button Shroud | No |
| Contact Quantity | 2 NO, 2 NO Push-Button |
| Contact Rating | 2 A @ 24 V dc |
| Dimensions (HxWxD mm ) | 269 x 46 x 58 |
| Actuation | Manual |
| Connection Type | Wiring Chamber |
