Banner DX80DR2M-H1-KR Industrial Wireless
The Banner DX80DR2M-H1-KR Industrial Wireless offers a Flex Power power, 10-30 V dc or 3.6-5.5 V dc low power option power supply, and IP67 rating. Manufactured by Banner under the Banner Industrial Wireless category, this model belongs to the DX Series.
| Power Supply | 10-30 V dc or 3.6-5.5 V dc low power option |
| Power | Flex Power |
| NEMA / UL Type Rating | NEMA 4X |
Banner DX80DR2M-H1-KR Industrial Wireless β Technical Specifications
| Specification | Value |
|---|---|
| Housing Style | Enclosed Terminals |
| IP Rating | IP67 |
| NEMA / UL Type Rating | NEMA 4X |
| Power | Flex Power |
| Input Output | Analog & Discrete |
| Device Type | Multihop Data Radio |
| Modbus RTU | Yes |
| RS-485 | Yes |
| Power Supply | 10-30 V dc or 3.6-5.5 V dc low power option |
| Input Details | 4 Discrete, 2 0-20 mA, 1 Thermistor, 1 counter |
| Max Temp Operating Conditions (Β°C) | 80 |
| LCD Display | Yes |
| Min Temp Operating Conditions (Β°C) | -20 |
| Ships With Battery | No |
| Point-to-Multipoint Topology | Yes |
| Point-to-Point Topology | Yes |
| Star Topology | Yes |
| Tree Topology | Yes |
| Application: Temperature Input | Yes |
| Wireless | Yes |
| Wireless Radio Frequency | 2.4 GHz |
| Cert: China | Yes |
| Cert: Korea | Yes |
| Cert: Brazil | Yes |
| Cert: Canada | Yes |
| Cert: Singapore | Yes |
| Analog Inputs | Yes |
| Discrete Inputs | Yes |
| Discrete Outputs | Yes |
| Output Details | 2 NMOS Discrete |
| Application: Object Counting | Yes |
