Banner DEE2R-875D Cordset
The Banner DEE2R-875D Cordset offers a Double Ended, M12 connection, 30 V ac/dc rating, and No Shield. Manufactured by Banner under the Banner Cordset category.
| Brand | Banner |
| Product Type | Cordsets |
| Model Number | DEE2R-875D |
Banner DEE2R-875D Cordset β Technical Specifications
| Specification | Value |
|---|---|
| IP Rating | IP68 |
| Cable Jacket Color | Yellow |
| Connector 1 Key Code | A |
| Cable Jacket Material | PVC |
| Coupling Nut Material | Nickel Plated Brass |
| Connector 1 Gender | Female |
| Connector 1 Orientation | Straight |
| Cordset Length (m) | 22.86 |
| Outside Cable Diameter (mm) | 5.46 |
| Connector 1 Number of Contacts | 8 |
| Number of Ends | Double Ended |
| Connector 2 Type | M12 |
| Connector 1 Type | M12 |
| Voltage Rating (V) | 30 V ac/dc |
| Minimum Temp. (Celsius) | -40 |
| Trunk Length (m) | No Trunk |
| Shield/No Shield | No Shield |
| Overmold Material and Color | PUR Black |
| Current Rating (A) | 2 |
| Maximum Temp. (Celsius) | 70 |
| Cordset Length Range (m) | Greater than 20.00 |
| Connector 2 Number of Contacts | 8 |
| Connector 2 Gender | Male |
| Connector 2 Orientation | Straight |
| Connector 2 Key Code | A |
