Banner CSB-UNT810M1282M1284.5 Cordset
The Banner CSB-UNT810M1282M1284.5 Cordset offers a , connection, 75 V ac/dc rating, and No Shield. Manufactured by Banner under the Banner Cordset category.
| Brand | Banner |
| Product Type | Cordsets |
| Model Number | CSB-UNT810M1282M1284.5 |
Banner CSB-UNT810M1282M1284.5 Cordset – Technical Specifications
| Specification | Value |
|---|---|
| IP Rating | IP20 |
| Voltage Rating (V) | 75 V ac/dc |
| Minimum Temp. (Celsius) | -40 |
| Trunk Length (m) | 3.05 |
| Shield/No Shield | No Shield |
| Current Rating (A) | 2 |
| Maximum Temp. (Celsius) | 105 |
| Branches: Orientations | Straight, Straight |
| Trunk: Cable Jacket Material | PVC |
| Branches: Genders | Female, Female |
| Branches: Number of Contacts | 8, 8 |
| Branches: Connector Types | M12, M12 |
| Branches: Cable Jacket Material | PVC, PVC |
| Splitter: Overmold Material and Color | PUR Black |
| Wiring | Parallel |
| Number of Branches | 2 |
| Trunk: Connector Type | Flying Leads |
| Trunk: Number of Contacts | 8 |
