Banner BWA-CS-001 Cordset
The Banner BWA-CS-001 Cordset offers a Double Ended, 7/8 in. (Mini) connection, 125 V ac/dc rating, and No Shield. Manufactured by Banner under the Banner Cordset category.
| Brand | Banner |
| Product Type | Cordsets |
| Model Number | BWA-CS-001 |
Banner BWA-CS-001 Cordset β Technical Specifications
| Specification | Value |
|---|---|
| IP Rating | IP67 |
| Cable Jacket Color | Black |
| Cable Jacket Material | PVC |
| Coupling Nut Material | Nickel Plated Brass |
| Connector 1 Gender | Female |
| Connector 1 Orientation | Straight |
| Cordset Length (m) | 2 |
| Outside Cable Diameter (mm) | 9.4 |
| Connector 1 Number of Contacts | 3 |
| Number of Ends | Double Ended |
| Connector 2 Type | AC Plug |
| Connector 1 Type | 7/8 in. (Mini) |
| Voltage Rating (V) | 125 V ac/dc |
| Minimum Temp. (Celsius) | -40 |
| Trunk Length (m) | No Trunk |
| Shield/No Shield | No Shield |
| Overmold Material and Color | PVC Black |
| Current Rating (A) | 9 |
| Maximum Temp. (Celsius) | 70 |
| Cordset Length Range (m) | 2.00-4.99 |
| Connector 2 Number of Contacts | 3 |
| Connector 2 Gender | Male |
| Connector 2 Orientation | Straight |
