Banner BES58-S1S60P-0D0QL0G0 Absolute Encoder
The Banner BES58-S1S60P-0D0QL0G0 Rotary Encoder offers a 6 shaft diameter, Synchronous flange type, 10-30 V dc power supply, and Integral QD connection. Manufactured by Banner under the Banner Rotary Encoder category, this model belongs to the BEH Series.
| Encoder Type | Absolute |
| Supply Voltage | 10-30 V dc |
| Connection | Integral QD |
Banner Absolute Encoder BES58-S1S60P-0D0QL0G0 Technical Specifications
| Specification | Value |
|---|---|
| Primary Housing Material | Aluminum |
| Encoder Type | Absolute |
| Housing Diameter (mm) | 58 |
| Shaft Diameter (mm) | 6 |
| Solid Shaft | Yes |
| Shaft Material | Stainless Steel |
| Supply Voltage | 10-30 V dc |
| Connection | Integral QD |
| QD Type/Cable Length | M23 |
| Environmental Rating | IP65 |
| Rotational Speed (RPM) | 12000 |
| Flange Type | Synchronous |
| Flange Material | Aluminum |
| Revolution | Single Turn |
| Steps/Revolution | 8192 |
| Resolution | Revolution: Single Turn , Steps/Revolution: 8192 |
| Number of Pins | 12 |
| Feature: Quick Disconnect | Yes |
| SSI | Yes |
| Axial Shaft Load | 40N |
| Radial Shaft Load | 110N |
