Home Brands Banner Cordsets BC-M8M4-24-2 Banner BC-M8M4-24-2 Cordset The Banner BC-M8M4-24-2 Cordset offers a Single Ended , M8 connection, 125 V ac/dc rating, and No Shield . Manufactured by Banner under the Banner Cordset category.
Brand Banner Product Type Cordsets Model Number BC-M8M4-24-2
Banner BC-M8M4-24-2 Cordset – Technical Specifications Specification Value IP Rating IP67 Cable Jacket Color Black Cable Jacket Material PVC Coupling Nut Material Nickel Plated Brass Connector 1 Gender Male Connector 1 Orientation Straight Cordset Length (m) 2 Outside Cable Diameter (mm) 3.8 Connector 1 Number of Contacts 4 Number of Ends Single Ended Connector 2 Type Flying Leads Connector 1 Type M8 Voltage Rating (V) 125 V ac/dc Minimum Temp. (Celsius) -40 Shield/No Shield No Shield Overmold Material and Color PUR Black Current Rating (A) 1.5 Maximum Temp. (Celsius) 105 Cordset Length Range (m) 2.00-4.99
