Banner BC-M23F12-M23M12-22-10 Cordset
The Banner BC-M23F12-M23M12-22-10 Cordset offers a Double Ended, M23 connection, 300 V ac/dc rating, and No Shield. Manufactured by Banner under the Banner Cordset category.
| Brand | Banner |
| Product Type | Cordsets |
| Model Number | BC-M23F12-M23M12-22-10 |
Banner BC-M23F12-M23M12-22-10 Cordset – Technical Specifications
| Specification | Value |
|---|---|
| Cable Jacket Color | Black |
| Cable Jacket Material | PVC |
| Coupling Nut Material | Nickel Plated Brass |
| Connector 1 Gender | Male |
| Connector 1 Orientation | Straight |
| Cordset Length (m) | 10 |
| Connector 1 Number of Contacts | 12 |
| Number of Ends | Double Ended |
| Connector 2 Type | M23 |
| Connector 1 Type | M23 |
| Voltage Rating (V) | 300 V ac/dc |
| Minimum Temp. (Celsius) | -25 |
| Shield/No Shield | No Shield |
| Overmold Material and Color | TPU Black |
| Current Rating (A) | 4 |
| Maximum Temp. (Celsius) | 80 |
| Cordset Length Range (m) | 10.00-19.99 |
| Connector 2 Number of Contacts | 12 |
| Connector 2 Gender | Female |
| Connector 2 Orientation | Straight |
