Banner BC-M12F8-M12M8-24-8 Cordset
The Banner BC-M12F8-M12M8-24-8 Cordset offers a Double Ended, M12 connection, rating, and No Shield. Manufactured by Banner under the Banner Cordset category.
| Brand | Banner |
| Product Type | Cordsets |
| Model Number | BC-M12F8-M12M8-24-8 |
Banner BC-M12F8-M12M8-24-8 Cordset β Technical Specifications
| Specification | Value |
|---|---|
| Cable Jacket Color | Black |
| Connector 1 Key Code | A |
| Cable Jacket Material | PVC |
| Coupling Nut Material | Nickel Plated Brass |
| Connector 1 Gender | Female |
| Connector 1 Orientation | Straight |
| Cordset Length (m) | 8 |
| Connector 1 Number of Contacts | 8 |
| Number of Ends | Double Ended |
| Connector 2 Type | M12 |
| Connector 1 Type | M12 |
| Shield/No Shield | No Shield |
| Overmold Material and Color | PUR Black |
| Cordset Length Range (m) | 5.00-9.99 |
| Connector 2 Number of Contacts | 8 |
| Connector 2 Gender | Male |
| Connector 2 Orientation | Straight |
| Connector 2 Key Code | A |
