Banner ATK-VR81Q6 Safety Relay
The Banner ATK-VR81Q6 Safety Relay offers 3, rating, Screw terminal type. Manufactured by Banner under the Banner Safety Relay category, this model belongs to the ATK Series.
| Supply Voltage | 24 V ac/dc +/- 15% |
| Safe Output Rating | Relay - 6 A |
| Power Consumption | 3 W / 3 VA |
Banner ATK-VR81Q6 Safety Relay β Technical Specifications
| Specification | Value |
|---|---|
| Type | AT Series Duo-Touch Two Hand Control Safety Relays |
| IP Rating | IP20 |
| Power | AC/DC Universal |
| Supply Voltage | 24 V ac/dc +/- 15% |
| Device Type | Safety Relay |
| PL Rating | e |
| SIL Rating | 3 |
| Vibration | 10-55 Hz at 0.35 mm |
| LCD Display | No |
| In-Series Diagnostics | No |
| Max Operating Temperature ( Β°C) | 50 |
| Relative Humidity | 90% @ 50Β° C |
| SISTEMA | PFHd = 1.5 x 10-9 |
| Safety Module Type | Two-Hand Control Module |
| Expandable | No |
| Dimension (H x W x D in mm) | 84 x 22.5 x 118 |
| Input Operation | Simultaneous <= 500 ms (500 ms typical) |
| Number of Safe Inputs | 1 |
| Input Configuration | 2 x complementary (contact or PNP) |
| Safety Input - Dual Channel (Solid-State) | 25 mA @ 24 V dc (1 complementary PNP pair per channel) |
| Independently Controlled Safe Outputs | 1 |
| Output Configuration | 2 NO |
| Safe Output Rating | Relay - 6 A |
| Splittable Safe Output | No |
| Mechanical Life (Operations in Millions) | 20 |
| Power Consumption | 3 W / 3 VA |
| Response Time (ms) | 35 (max.) |
| Terminal Type | Screw |
| Removable Terminals | Yes |
| Electrical Life (Cycles @ VA) | 1,000,000 @ 250 VA |
| Safety Category Rating | 4 |
| Gate Switch (NC/NC) Input | No |
| Gate Switch (NC/NO) Input | No |
| Gate Switch (OSSD) Input | No |
| Light Curtains/Scanner with EDM Input | No |
| Light Curtains/Scanner without EDM Input | No |
| Safety Input - Dual Channel (Dry Contact) | 25 mA @ 24 V dc (1 NO / 1 NC per channel) |
| THC Rating | IIIC |
| Two-Hand Controls | Yes |
