QS30EDVQPMA: 75703 - Banner NPN/PNP Output Diffuse-mode Sensor

QS30EDVQPMA 75703 Banner NPN/PNP Output Diffuse-mode Sensor

SpecValue
BrandBanner
Product TypePhoto sensor
ProductQS30EDVQPMA

Banner NPN/PNP Output Diffuse-mode Sensor QS30EDVQPMA, 75703 Technical Specifications:

SpecificationValue
IP RatingIP67
Sensing BeamVisible Red LED
NEMA / UL Type RatingNEMA 4X
Sensing Mode (Detailed)Diffuse
Housing StyleRectangular w/M30 Mount
Primary Housing MaterialThermoplastic
Laser Classification-
Input OutputDiscrete
Connection TypeM12
Max Sensing Distance (mm)1400
OutputsBipolar (NPN & PNP)
Power Supply10-30 V dc
AdjustmentsTeach Button
Max Op Temp (°C)55
Min Op Temp (°C)-10
Number of Pins5
Output response time (ms)0.3-1.8
Small Visible Spot-
Sensing Beam Wavelength660
Delay at Power-up (ms)250
Repeatability (µs)100 to 150
Max Op Relative Humidity95% @ 50°C
Lens MaterialAcrylic
Barrel Diameter (mm)30
IndicatorBargraph
Request the pricing for the Banner NPN/PNP Output Diffuse-Mode Sensor QS30EDVQPMA (Part No: 75703) at unbeatable prices. The QS30EDVQPMA offers IP67 rating, ensuring high durability and suitability for harsh environments. It features a Visible Red LED, with a Diffuse sensing mode, housed in a rectangular housing with an M30 mount. The primary housing material is thermoplastic, supporting a maximum sensing distance of 1400 mm. The Banner photoelectric sensor operates within a power supply range of 10-30 V DC, functioning efficiently between -10°C and 55°C with 5 pins. The sensing beam wavelength is 660 nm, and the power-up delay is 250 ms. It also includes an Acrylic lens with Bargraph indicators for status display. Now's the time to secure a quote for your Banner NPN/PNP Output Diffuse-mode Sensor. Trust in our more favorable pricing and responsive support compared to other traders. For detailed specifications, access the QS30EDVQPMA datasheet and PDF.
