Autonics SRHL1-1225 Solid State Relay
The SRHL1-1225 Autonics Single-Phase Solid State Relays supports 25A load current, 10-30VDC input voltage, and 24-240VAC load voltage. The SRHL1-1225 belongs to Autonics Single-Phase Solid State Relays and the SR1 Series with zero cross turn-on, integrated heatsink, panel or DIN rail mounting, and reinforced dielectric insulation for industrial automation applications.
| Brand | Autonics |
| Product Type | Solid State Relay |
| Model Number | SRHL1-1225 |
Autonics SRHL1-1225 Solid State Relay – Technical Specifications
| Specification | Value |
|---|---|
| Control phase | Single-phase |
| Mounting type | Panel, DIN rail |
| Rated input voltage | 10-30VDC |
| Rated load voltage | 24-240VAC~ |
| Dielectric strength | Input-output: 2500VAC 50/60Hz for 1 min. Input/output-case: 4000VAC 50/60Hz for 1 min |
| Rated load current | 25A |
| Function | Zero cross turn-on |
| Heatsink | Heatsink |
| Alarm(Overheat Prevention) | Alarm indicator |
| Environment_Ambient temperature | -30 to 70℃, storage: -30 to 100℃(The rated load current capacity is different depending on ambient temperature. Refer to '▣ SSR Derating Curve'.) |
| Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
| Weight | Approx. 270g(approx.192g) |
The SRHL1-1225 Autonics Single-Phase Solid State Relays is designed for industrial automation systems requiring dependable switching and electrical isolation. The SRHL1-1225 supports 25A rated load current, 10-30VDC rated input voltage, 24-240VAC rated load voltage, and 4000VAC case insulation strength between circuits and housing. This model belongs to the SR1 Series and is used in industrial automation equipment where stable load control and reliable solid-state switching are required. Autonics manufactures this relay for applications requiring controlled AC load operation and consistent switching performance.
The SRHL1-1225 is suitable for conveyors, packaging machines, assembly equipment, heaters, and automated production systems. Its zero cross turn-on function helps reduce electrical noise during switching and supports stable operation of connected AC loads. The integrated heatsink assists heat dissipation during continuous operation, while panel and DIN rail mounting options provide installation flexibility. Autonics solid state relays are commonly used where dependable switching cycles, stable load control, and reliable automation performance are required in industrial environments.
SRHL1-1225 from Autonics combines single-phase load control and solid-state switching for industrial automation environments. The relay supports 25A load handling capacity, 24-240VAC load voltage operation, and 10-30VDC input control signals. Autonics SR1 Series relays are widely integrated into industrial control systems because of stable switching performance, electrical isolation, integrated heatsink construction, and zero cross turn-on operation. The SRHL1-1225 Autonics Single-Phase Solid State Relays is suitable for automation panels, production equipment, and industrial machinery requiring reliable AC load switching and control.
