Autonics SR3-2440 Solid State Relay
The Autonics SR3-2440 Solid State Relay offers 3-phase control, Panel Mounting type, 24VAC~ input voltage, 48-480VAC~ load voltage. Manufactured by Autonics under the Autonics Solid State Relay category, this model belongs to the Autonics SR Series.
| Brand | Autonics |
| Product Type | Solid State Relay |
| Model Number | SR3-2440 |
Autonics SR3-2440 Solid State Relay β Technical Specifications
| Specification | Value |
|---|---|
| Control phase | 3-phase |
| Mounting type | Panel |
| Rated input voltage | 24VAC~ |
| Rated load voltage | 48-480VAC~ |
| Dielectric strength | 4,000VAC~ |
| Rated load current | 40A |
| Function | Zero cross turn-on |
| Environment_Ambient temperature | -30 to 80β(in case of the rated input voltage 90-240VAC~: -30 to 70β), Storage: -30 to 100β( The rated load current capacity is different depending on ambient temperature. Refer to 'β£ SSR Derating Curve'.) |
| Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
| Weight | approx. 365g(approx. 275g) |
Obtain a Quote for Autonics 3-Phase SSR Detachable Heatsink Type SR3-2440 at economical prices. Specifications Overview for SR3-2440 reveals 3-phase Control Relay with superior performance and durability. Designed for Panel mounting, this relay ensures easy installation in various industrial applications. It operates on a rated input voltage of 24VAC~, providing reliable control for automation systems. The rated load voltage of 48-480VAC~ makes it suitable for diverse electrical loads. Featuring a dielectric strength of 4,000VAC~, it guarantees high insulation performance, ensuring operational safety. The rated load current of 40A supports heavy-duty applications, offering efficient power handling. Equipped with a Zero cross turn-on function, it enhances switching stability, reducing electrical noise and extending the relayβs lifespan. Built for rugged environments, it operates reliably in ambient humidity levels of 45 to 85% RH, storage: 45 to 85% RH, ensuring consistent performance. With a weight of approximately approx. 365g(approx. 275g), it is compact yet robust. Take the First Step with a Quote for your requirement of 3-Phase SSR Detachable Heatsink Type. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
