Autonics SFN-M-020 Safety Door Switches
The Autonics SFN-M-020 Safety Door Switch offers opening force, , , 100Hz Operating frequency. Manufactured by Autonics under the Autonics Safety Door Switch category, this model belongs to the Autonics SFN Series.
| Brand | Autonics |
| Product Type | Safety Non-Contact Door Switches |
| Model Number | SFN-M-020 |
Autonics SFN-M-020 Safety Door Switches β Technical Specifications
| Specification | Value |
|---|---|
| Operating frequency | 100Hz |
| Vibration_Malfunction | 1.0 mm amplitude at frequency of 10 to 55 Hzin each X, Y, Z direction for 10 min |
| Shock | 300m/sΒ² (approx. 30G) in each X, Y, Z direction for 3 times |
| Shock_Malfunction | 300m/sΒ² (approx. 30G) in each X, Y, Z direction in output ON/OFF status for 3 times |
| Protection structure | IP67(IEC standard) |
| Material | Body/CAP: PC |
| Operation distance_OFFβON | β₯ 5 mm |
| Operation distance_ONβOFF | β€ 15 mm |
| Power supply | 24VDC@(=)Β±10% |
| Power consumption | β€ 400mA |
| Sub output | PNP open collector output - 24 VDC, 10 mA |
| Operation indicator | ON: green, OFF: red |
| Life expectancy | β₯ 20,000,000 times (with low load) |
| Protection circuit | Surge protection circuit, output short over current protection circuit, reverse polarity protection circuit |
| Dielectric strength | 1,500 VAC~ 50/60Hz for 1 minute |
| Vibration | 1.0 mm amplitude at frequency of 10 to 55 Hzin each X, Y, Z direction for 2 hours |
| Ambient temperature | -10 to 55β, storage: -20 to 60β |
| Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Connection | Cable type |
| Connector type | M12 Connector |
| Insulation resistance | β₯ 50 MΞ© (500 VDC@(=) megger) |
| Weight | Approx. 100.5g(approx. 113.8g) |
Autonics developed the SFN-M-020 for demanding Safety Non-Contact Door Switch applications. Operating on a stable 24VDC Β±10% supply, it delivers reliable position detection without physical contact, minimizing wear and extending service life.
This model offers an operating frequency of 100Hz with an OFFβON actuation distance of β₯5 mm and ONβOFF distance of β€15 mm, providing quick and accurate door status monitoring. The PNP open collector sub-output (24VDC, 10 mA) integrates easily with safety control systems, and its dual-color LED indicator allows clear status verification.
Constructed from durable polycarbonate with an IP67 protection rating, the SFN-M-020 withstands shock up to 30G, vibration from 10β55Hz, and operates between -10Β°C to 55Β°C. Learn more at Autonics Sensors & Controllers for industrial automation or the full range of Autonics Safety Door Switches.
The Autonics SFN-M-020 Safety Door Switch is ideal for securing machine access panels, robotic cell doors, and conveyor safety gates. Its non-contact operation prevents mechanical wear, making it suitable for environments with frequent access cycles. Engineers value its simple wiring and rugged build, while safety managers trust its consistent operation in high-vibration, moisture-prone, or dusty conditions.
