Autonics SFD-MA2B-2G1/2 Safety Door Switches

Name: Autonics SFD-MA2B-2G1/2
Brand: Autonics
SKU: SFD-MA2B-2G1/2
Rating: 4.7 (4 reviews)

The Autonics SFD-MA2B-2G1/2 Safety Door Switch offers Min. 80N opening force, Min. 10mm, 0.05 to 1m/s, Max. 20/min Operating frequency. Manufactured by Autonics under the Autonics Safety Door Switch category, this model belongs to the Autonics SFD Series.

Datasheet

Brand	Autonics
Product Type	Safety Door Switches
Model Number	SFD-MA2B-2G1/2

Autonics SFD-MA2B-2G1/2 Safety Door Switches – Technical Specifications

Specification	Value
Directing opening force	Min. 80N
Directing opening distance	Min. 10mm
Operating speed	0.05 to 1m/s
Operating frequency	Max. 20/min
Life cycle_Mechanical	Min. 1,000,000 operations
Vibration_Malfunction	0.75mm amplitude at frequency of 10 to 55Hzin each X,Y,Z direction for 10 min
Shock	1,000m/s² (approx. 100G) in each X, Y, Z direction for 3 times
Shock_Malfunction	300m/s² (approx. 30G) in each X, Y, Z direction for 3 times
Environment_Ambient temperature	-30 to 70℃, storage: -40 to 70℃
Environment_Ambient humidity	35 to 90%RH, storage : 35 to 90%RH
Protection structure	IP67(IEC standerd, except head)
Material	Head: zinc, case: polyamide 6, operation key: stainless steel 304
Applicable cable	AWG 20-18 (0.5 to 0.75mm²)
Sold separately	Operation key
Dielectric strength_Between the terminals	2kV
Connection Type	G1/2 Connector cable
Rated load voltage & current	Resistive load : 6A/250VAC~, 0.6A/250VDC@(=)Inductive load : AC-15 3A/240VAC~,DC-13 0.27A/250VDC@(=)
Dielectric strength_Between each terminal and non-live part	5kV
Insulation resistance	100MΩ or more (500VDC megger basis)
Contact resistance	Max. 50mΩ (initial value)
Life cycle_Electrical	Min. 100,000 operations (240VAC~ 6A)
Conditional short circuit current	100A
Weight	Approx. 170g(approx. 130g)
