Autonics S3PF-P3R2BLM - 30 mm Push Button Switches
Autonics 30 mm Push Button Switches S3PF-P3R2BLM Technical Specifications
| Brand | Autonics |
| Product Type | Control Switches |
| Product | S3PF-P3R2BLM |
Autonics 30 mm Push Button Switches S3PF-P3R2BLM Technical Specifications
| Specification | Value |
|---|---|
| Contact block_Electrical specification_Power voltage/current | 110VAC~/10A, 250VAC~/6A |
| LED block_Power supply | 110-220VAC~ 50/60Hz |
| LED block_Current consumption | Max. 20mA |
| Button type | Flush |
| Illuminated | Illuminated |
| Letter marking | Marking(Push) |
| Color | Red |
| Contact block | B contact: 2 |
| Contact block type | Modular type |
| Environment_Ambient temperature | -15 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP52 |
| Weight_Housing | Approx. 7g |
| Weight_Contact block_Modular type A/B contact | Approx. 10g |
| Weight_LED block_AC voltage type | Approx. 12g |
| Weight_Mounting hole_Ø30 | Approx. 21.5g |
