Autonics S3KF-5ESABM - 30 mm Key Selector Switches
Autonics 30 mm Key Selector Switches S3KF-5ESABM Technical Specifications
| Brand | Autonics |
| Product Type | Control Switches |
| Product | S3KF-5ESABM |
Autonics 30 mm Key Selector Switches S3KF-5ESABM Technical Specifications
| Specification | Value |
|---|---|
| Contact block_Electrical specification_Power voltage/current | 110VAC~/10A, 250VAC~/6A |
| Color | Silver |
| Operation type | 3-position, spring return from right |
| Contact block | A contact: 1, B contact: 1 |
| Contact block type | Modular type |
| Key removal position | Center |
| Environment_Ambient temperature | -15 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP52 |
| Weight_Housing | Approx. 7g |
| Weight_Contact block_Modular type A/B contact | Approx. 10g |
| Weight_Mounting hole_Ø30 | Approx. 41g |
