Autonics S3KF-1ES2AM - 30 mm Key Selector Switches
Autonics 30 mm Key Selector Switches S3KF-1ES2AM Technical Specifications
| Brand | Autonics |
| Product Type | Control Switches |
| Product | S3KF-1ES2AM |
Autonics 30 mm Key Selector Switches S3KF-1ES2AM Technical Specifications
| Specification | Value |
|---|---|
| Contact block_Electrical specification_Power voltage/current | 110VAC~/10A, 250VAC~/6A |
| Color | Silver |
| Operation type | 2-position, spring return |
| Contact block | A contact: 2 |
| Contact block type | Modular type |
| Key removal position | Center |
| Environment_Ambient temperature | -15 to 55โ, storage: -25 to 65โ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP52 |
| Weight_Housing | Approx. 7g |
| Weight_Contact block_Modular type A/B contact | Approx. 10g |
| Weight_Mounting hole_ร30 | Approx. 41g |
