Autonics S2TR-P3W2BD - 22/25 mm Double Push Button Switches
Autonics 22/25 mm Double Push Button Switches S2TR-P3W2BD Technical Specifications
| Brand | Autonics |
| Product Type | Control Switches |
| Product | S2TR-P3W2BD |
Autonics 22/25 mm Double Push Button Switches S2TR-P3W2BD Technical Specifications
| Specification | Value |
|---|---|
| Contact block_Electrical specification_Power voltage/current | 110VAC~/10A, 250VAC~/6A |
| LED block_Power supply | 12-24VAC~ 50/60Hz, 12-24VDC @(=) |
| LED block_Current consumption | Max. 20mA |
| Button type | [Illuminated] Extended |
| Contact block | B contact: 2 |
| Contact block type | Singular type |
| Environment_Ambient temperature | -15 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP50 |
| Weight_Housing | Approx. 7g |
| Weight_Contact block_Singular type A/B contact | Approx. 11g |
| Weight_LED block_AC/DC voltage type | Approx. 11g |
| Weight_Mounting hole_Γ22/25 | Approx. 14.5g |
