Autonics S2SR-S7W2A - 22/25 mm Selector Switches
S2SR-S7W2A is an Autonics 22/25 mm Selector Switch with 90º left-right angle and 110-250VAC rating. Manufactured by Autonics, this model belongs to Autonics Control Switches and the S2SRN Series for industrial automation in India. It features 90º left and right operation angle, 110VAC~/10A and 250VAC~/6A contact rating, 2NO singular contact blocks, IP52 protection structure, short lever 3-position maintained operation, white actuator, and defined mounting structure weights.
| Brand | Autonics |
| Product Type | Control Switch |
| Model Number | S2SR-S7W2A |
Autonics 22/25 mm Selector Switches S2SR-S7W2A Technical Specifications
| Specification | Value |
|---|---|
| Mechanical characteristics_Operation angle | Left 90º , Right 90º |
| Contact block_Electrical specification_Power voltage/current | 110VAC~/10A, 250VAC~/6A |
| Contact block | A contact: 2 |
| Contact block type | Singular type |
| Operation type | Short lever 3-position, maintained |
| Color | White |
| Environment_Ambient temperature | -15 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP52 |
| Weight_Contact block_Singular type A/B contact | Approx. 11g |
| Weight_Mounting hole_Ø22/25 | Approx. 19g |
| Weight_Housing | Approx. 7g |
TheS2SR-S7W2A Autonics 22/25 mm Selector Switches is structured for multi-position control in industrial automation panels. The S2SR-S7W2A supports 110VAC~/10A and 250VAC~/6A electrical capacity and operates with a 90º left and right mechanical angle. It integrates 2NO singular contacts and maintains IP52 protection. As part of the S2SRN Series, S2SR-S7W2A enables defined three-position maintained selection in control circuits.
In conveyor systems, packaging machinery, assembly lines, and machine control cabinets, S2SR-S7W2A Autonics 22/25 mm Selector Switches provides stable switching between operational states. The short lever 3-position maintained mechanism ensures clear mechanical positioning. Its specified voltage rating supports structured direction control, mode selection, or process switching within industrial automation systems across India.
Autonics S2SR-S7W2A within Autonics 22/25 mm Selector Switches category delivers defined mechanical operation and specified electrical ratings for panel integration. With IP52 enclosure protection and dual contact configuration, S2SR-S7W2A aligns with industrial control requirements. Autonics maintains consistent manufacturing standards, and S2SR-S7W2A under the S2SRN Series remains suitable for dependable selector switch applications.
