Autonics PWEB-102-R Signal Light
The Autonics PWEB-102-R Signal Light offers Steady, Buzzerfunction, 24VAC/DC power supply, Red lens color, Lead wire connection type. Manufactured by Autonics under the Autonics Signal Lights category, this model belongs to the Autonics MS Series.
| Brand | Autonics |
| Product Type | Signal Lights |
| Product | PWEB-102-R |
Autonics PWEB-102-R Signal Light – Technical Specifications
| Specification | Value |
|---|---|
| Function | Steady, Buzzer |
| Power supply | 24VAC/DC |
| Current consumption | 0.16A |
| LED color | Red |
| Lens color | Red |
| Dimension | W90×D25×H194mm |
| Buzzer volume | 80±5dB (at 1m) |
| Mounting direction | Wall mounting |
| Connection type | Lead wire connection |
| Cable specification | UL1007/22AWG |
| Storage ambient temperature | -20~70℃ |
| Ambient temperature | -20~40℃ |
| Ambient humidity | 45 to 85%RH |
| Insulation resistance | 100MΩ or more (500VDC megger basis) |
| Vibration | 0.75mm at 10~55Hz |
| Protection structure | IP52 |
