Autonics PTM-LCF-102-RYG Tower Light
The Autonics PTM-LCF-102-RYG Tower Light offers Steady, Flashingfunction, 24VAC/DC power supply, 1color-Clear lens color, Lead wire connection type. Manufactured by Autonics under the Autonics Tower Light category, this model belongs to the Autonics PTM Series.
| Brand | Autonics |
| Product Type | Tower Lights |
| Model Number | PTM-LCF-102-RYG |
Autonics PTM-LCF-102-RYG Tower Light β Technical Specifications
| Specification | Value |
|---|---|
| Function | Steady, Flashing |
| Power supply | 24VAC/DC |
| Current consumption | 0.035A |
| LED color | 3colors-Red, Yellow, Green |
| Lens color | 1color-Clear |
| Dimension | D56mm |
| Flashing rate | 80Β±5times/minute |
| Mounting direction | Upward only |
| Connection type | Lead wire connection |
| Cable specification | UL1007/22AWG |
| Ambient temperature | -15~40β |
| Storage ambient temperature | -20~70β |
| Ambient humidity | 45 to 85%RH |
| Insulation resistance | 100M⦠or more (500VDC megger basis) |
| Vibration | 0.75mm at 10~55Hz |
| Protection structure | IP65 |
