Autonics PT6-4DP5-5 - M12 5-pin Connector Distribution Boxes
Technical Specifications of Autonics M12 5-pin Connector Distribution Boxes PT6-4DP5-5:
| Brand | Autonics |
| Product Type | Distribution Boxes |
| Product | PT6-4DP5-5 |
Autonics M12 5-pin Connector Distribution Boxes PT6-4DP5-5 Technical Specifications
| Specification | Value |
|---|---|
| Number of ports | 6-port |
| Input logic | PNP |
| Power supply | 12-24VDC @(=) |
| Rated current | 2A(per signal), 4A(per port), 10A(total) |
| Connection life cycle | Min. 200 operations |
| Number of M12 connector pins | 5-pin |
| Protection structure | IP67(waterproof cover), IP52(protection cover) |
| Connection method for external signal | Cable type |
| Leakage current | Max. 0.5mA |
| Output type_1/2-Signal(DC 4-Wire type) | 2-Signal(DC 4-Wire type) |
| Cable length | 5m |
| Material | Case: PBT (G15%), Name plate: PC, General cable (black): Polyvinyl chloride (PVC) |
| Environment_Ambient temperature | -25 to 75, storage: -30 to 80 |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 1430g (approx. 1230g) |
