Autonics PSN30-15AO Proximity Sensor
The Autonics PSN30-15AO Proximity Sensor operates with an AC 2-wire type 100β240VAC~ supply, offering a 15mm sensing distance and durable 30mm frame size for industrial detection needs. Manufactured by Autonics, it features a standard sensing target of 45Γ45Γ1mm (iron) and Normally Open control output for dependable switching performance. Available under Autonics Proximity Sensors, this model ensures IP67 protection structure, maximum 10% hysteresis, and lightweight design of approximately 92g. Part of the Autonics PS Series, it delivers consistent sensing accuracy in demanding applications.
| Brand | Autonics |
| Product Type | Proximity Sensors |
| Model Number | PSN30-15AO |
Autonics PSN30-15AO Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Wire type and power | AC 2-wire type100-240VAC~ |
| Sensing side size | Frame size 30mm |
| Sensing distance | 15mm |
| Standard sensing target | 45Γ45Γ1mm(iron) |
| Response frequency | 20Hz |
| Current specification | Leakage current: Max. 2.5mA |
| Control output | Normally Open |
| Sensing type | Standard type(front sensing type) |
| Material | Heat-resistant ABS |
| Protection structure | IP67 |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Weight | β 92g (β 161g) |
The Autonics PSN30-15AO Proximity Sensor is built on an AC 2-wire system operating at 100β240VAC, allowing simple wiring and compatibility with a wide range of industrial controllers. With its 30mm rectangular frame size and 15mm sensing distance, it offers accurate detection of metallic targets, using a standard 45Γ45Γ1mm iron plate. Supporting a 20Hz response frequency, it delivers dependable performance even in slower moving automation processes, while a maximum leakage current of just 2.5mA ensures energy-efficient operation.
Engineered with heat-resistant ABS material and certified to IP67 protection standards, the sensor provides long-lasting durability against dust, oil, and water exposure. Its Normally Open control output integrates seamlessly with PLCs and control systems, while the front sensing type design allows precise detection even in compact or edge-mounted installations. Operating reliably in ambient temperatures from -25β to +70β and humidity up to 95% RH, the PSN30-15AO maintains stable sensing in challenging plant environments.
Industrial users rely on the Autonics PSN30-15AO Rectangular Inductive Proximity Sensor for applications such as position detection in conveyors, metal presence verification in packaging lines, and end-position feedback in assembly machinery. Maintenance teams value its durability and quick installation, while junior engineers can use it to understand proximity sensing principles in real-world automation. Trusted across sectors like automotive, textiles, and heavy machinery, the Autonics PSN30-15AO continues to be a preferred solution for engineers seeking accuracy, efficiency, and long-term reliability. For more details, visit the Autonics Proximity Sensors page or the complete Autonics Sensors & Controllers range.
