Autonics PSN30-10DN Proximity Sensor
The Autonics PSN30-10DN Proximity Sensor operates on a DC 3-wire type 12β24VDC system, providing a 10mm sensing distance with a durable 30mm frame size for precise industrial detection. Manufactured by Autonics, it includes a standard sensing target of 30Γ30Γ1mm (iron) and NPN Normally Open control output for reliable performance. Available under Autonics Proximity Sensors, this model ensures IP67 protection structure, maximum 10% hysteresis, and durable construction weighing approximately 96g. Part of the Autonics PS Series, it delivers stable operation in demanding automation environments.
| Brand | Autonics |
| Product Type | Proximity Sensors |
| Model Number | PSN30-10DN |
Autonics PSN30-10DN Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Wire type and power | DC 3-wire type 12-24VDC |
| Sensing side size | Frame size 30mm |
| Sensing distance | 10mm |
| Standard sensing target | 30Γ30Γ1mm(iron) |
| Response frequency | 250Hz |
| Current specification | Current consumption: Max. 10mA |
| Control output | NPN Normally Open |
| Sensing type | Standard type(front sensing type) |
| Material | Heat-resistant ABS |
| Protection structure | IP67 |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Weight | β 96g (β165g) |
The Autonics PSN30-10DN Proximity Sensor is engineered with a compact 30 mm rectangular housing and offers a precise sensing distance of 10 mm. Operating on a DC 3-wire 12β24VDC supply, it features an NPN Normally Open control output and supports a fast response frequency of 250 Hz. With a low current consumption of just 10 mA, it ensures energy-efficient performance while maintaining high reliability.
The sensing surface is designed for front detection and is optimized for a standard 30Γ30Γ1 mm iron target. Built with heat-resistant ABS material, the sensor is both durable and lightweight, weighing approximately 96 g. The IP67-rated protection makes it resistant to water, dust, and industrial contaminants, ensuring consistent performance in demanding environments. It also maintains stability within a wide temperature range of -25Β°C to +70Β°C, making it suitable for diverse applications.
Applications of the Autonics Rectangular Inductive Proximity Sensor PSN30-10DN extend across automotive manufacturing, packaging lines, assembly conveyors, and CNC machines where accurate, non-contact detection is essential. Maintenance engineers rely on it for reliable part positioning and quality control, while students and young professionals find it useful in learning automation systems. The combination of compact design, IP67 durability, and high-speed response ensures that this sensor is trusted for long-term use in industrial environments. For more details, visit the official Autonics Sensors & Controllers page or the full range of Autonics Proximity Sensors.
